Onduline Easyline Bitumen Black Corrugated Sheets 760x1000mm

Description Technical Data Guide Sheet Width:  760mm Wide Sheet Length:  1000mm Long Sheet Thickness:  2.6mm Weight Per Sheet:  2.3kg Reaction To Fire (EN13501-1):  E Manufacturers Recommended Batten Spacing:  430mm (maximum) For roofs above 10º pitch. Minimum Pitch:  5 Degrees – NOTE – Roof pitches below 10º MUST be boarded. Recommended Head Lap 10º :  150mm Recommended Head Lap 5º – 10º:  300mm Recommended Side Lap 10º :  1 Corrugation Recommended Side Lap 5º – 10º:  2 Corrugations
